Measure: Aquire the necessary data using the digitizer, micrometers, calipers, etc.
Design: Create the 3D model. Use calculations and analysis to iterate the design.
Build: Use established fabricators to make the actual prototype.
Click on the menu buttons to the left for in-depth descriptions of services available.
Important mating parts, pieces of the product environment, or clay models and sketches that you may have are digitized into the 3D environment.
Starting with your concept, the product is designed to meet your price and performance requirements. This is done with a focus on design for manufacturing - knowing how to design the part to utilize common manufacturing methods.
All 3D modeling is done in SolidWorks, allowing the creation of complex solid models and surfaces.
For the purpose of reviewing and evaluating the design, one or more prototype samples can be made. These samples are printed in 3D from the CAD models or manufactured by local vendors.
Prototyping Services:
The 2D drawings show acceptable tolerances, the material and surface finish, and all other requirements not found in the 3D model. All drawings are made using the industry standard geometric tolerancing and dimensioning (GD&T) specification, ASME Y14.5M-1994.
A BOM (bill of material) document can automatically be generated from the 3D assembly model.
If you require line-art views of the assemblies for owner or training manuals, these can be provided.
Drawings and models are sent to vendors for quotation. Any feedback from the vendors on how to further reduce cost can be incorporated into the design.
